CRL PTC037CH Polished Chrome Pinnacle 3 – Point Movable Beveled Style Transom Clamp

Our CRL 3-Point Movable Transom Clamps provides design alternatives to the traditional side mounted “teeter-totter” application. Mounted to the ceiling instead of the sides of the transom allows more glass exposure. The Clamps will hold at 45 degrees inward, at the closed position, and at 45 degrees outward. The square or beveled appearance matches many of our popular Hinge Series. Available finishes are Polished Chrome, Polished Brass, Brushed Nickel, Oil Rubbed Bronze, and Satin Chrome. Accommodates 1/2″, 3/8″, and 5/16″ (12, 10, and 8 mm) thick tempered glass.
SPECIFICATIONS:

Glass Thickness: 5/16″ to 1/2″ (8 to 12 mm)

Material: Solid Brass

Includes: Gaskets, Mounting Screws, Phillips Screws,
Allen Screws, and Glass Fabrication Dimensions

Gaskets are included for 3/8″ and 1/2″ (10 and 12 mm) glass only. If using 5/16″ (8 mm) glass, Cat. No. P1N13 Gaskets must be ordered.
Cut-Out Required
NOTE: Maximum transom size is 28″ W x 12″ H (711 x 305 mm). Two Clamps must be used per transom. It is recommended to come in 6″ (152 mm) to the center of the cutout for each Clamp.
